Power Options:
|
|
Features:
Pure sine wave inverter
Built-in PWM solar charge controller
Configurable input voltage range for home applicances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC/Solar charger priority via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/over temperature/ short circuit protection
Smart charging system optimizes battery performance
Cold start function
1 LCD display
2.Status indicator
3.Charging indicator
4.Fault indicator
5.Function buttons
6.Power on/off swtich
7.AC input
8.AC output
9.PV input
10.Battery input
11. Circuit Breaker
12. RS232 communication port
13.Parallel communication cable (only for parallel model)
14.Current sharing cable (only for parallel model)
15.Dry Contact
What's in the package:
The unit x 1
User Manual(English) x 1
Communication cable x 1
Software CD x 1
